WME >> Winch >> Hand Winch
|
Hand WinchH.S. 8425 3990
|
|
|
| Model | Capacity | Breaking Force |
Gear Ratio |
Direction/Speed | Machine Weight |
Dimension L * W * H |
Note | Photo |
| BQS-600 | 600LBS/250KGS | 375KGS | 3.2:1 | 1 direction / 1 speed | ||||
| BQS-800 | 800LBS/350KGS | 525KGS | 3.2:1 | 1 direction / 1 speed | ||||
| BQS-1000 | 1000LBS/450KGS | 675KGS | 4.1:1 | 2 direction / 1 speed | ||||
| BQS-1200 | 1200LBS/550KGS | 825KGS | 4.1:1 | 2 direction / 1 speed | ||||
| BQS-1400 | 1400LBS/600KGS | 900KGS | 4:1 | 2 direction / 1 speed | ||||
| BQS-1600 | 1600LBS/700KGS | 1050KGS | 4:1 | 2 direction / 1 speed | ||||
| BQS-1800 | 1800LBS/800KGS | 1200KGS | 4.1:8.1 | 2 direction / 2 speed | ||||
| BQS-2000 | 2000LBS/900KGS | 1350KGS | 4.1:8.1 | 2 direction / 2 speed | ||||
| BQS-2500 | 2500LBS/1100KGS | 1650KGS | 4.1:8.1 | 2 direction / 2 speed |
|
All specifications are approximate. Specifications are subject to change without notice. |
|
