| Model |
BN0501 |
| Nav Method |
Laser SLAM/Visual/IMU Fusion Nav |
| LWH |
1475×735×540mm |
| Self-Wt |
170kg |
| Rated Load |
500kg |
| Load Center Dist |
600mm |
| Fork Height |
70mm |
| Straight Stacking Channel Width |
2040mm |
| Laser Sensor |
Single Laser |
| Touch Screen |
7-Inch |
| Main Drive Dir |
Forward |
| Travel Speed |
0.7m/s/1.0m/s (Loaded/Unloaded) |
| Fork Lift Speed |
/ |
| Gradeability |
2%/3% (Loaded/Unloaded) |
| Overpass & Step Capability |
/ |
| Repeat Pos Accuracy |
±5mm/1° |
| Line Recog Accuracy |
±10mm |
| Battery Spec |
48V/24Ah Li-Iron Phosphate Batt |
| Charging Time |
1.5h |
| Cont Op Time |
>5h |
| Battery Life |
1500 Cycles |
| Charging Mode |
Auto/Manual |
| Laser Obstacle Avoidance |
Std |
| Depth Vision Obstacle Stop |
Std |
| Safety Edge |
Std |
| Emergency Stop |
Std |
| Audible-Visual Alarm |
Std |
| Indoor/Outdoor |
Indoor |
| Single Map Size |
>1000000㎡ |
| Working Temp |
-10~40°C |
| Working Humidity |
10%-90% No Condensation |
| Air Env |
No Dust, Flammable, Explosive, Corrosive Gases |
| Air Env |
IEEE 802.11a/b/g/n/ac |
|
|
