| Model |
CT105K |
| Empty weight |
39 |
| Overall dimensions (mm) |
9440×3750×4260 |
| Mode of drive |
6×4 |
| Wheelbase (mm) |
3800 + 1720 |
| Maximum climb angle (%) |
32 |
| Minimum turning diameter (m) |
23 |
| Minimum ground clearance (mm) |
370 |
| Cab type |
Rear - left forward - tilting narrow cab with left - hand position and forward tilt |
| Auxiliary safety equipment |
Reversing image system, reversing camera |
| Box dimensions (mm) |
6000×3500×1910 |
| Box material and thickness (mm) |
NM450 12/16 |
| Hydraulic lifting system |
196 |
| Underbox heating system |
standard |
| Engine model |
WP13G530E470/YCK16775 - T300/YCDV160A3 - 770 |
| Steering system |
fully hydraulic |
| Gearbox |
8DS260A/8DS240A |
| Fuel tank (L) |
600 L two - chamber, with fuel heating |
| Frame |
700L high - strength flexible frame (8 + 10 + 10 + 12) |
| Front suspension |
longitudinal spring/air suspension |
| Thickness/width/quantity front leaf spring |
22/100/13 |
| Rear suspension |
patented 150T leaf spring suspension |
| Rear leaf spring Thickness/width/number |
33/120/15 |
| Differential |
Interaxle differential lock |
| Front and rear axle load capacity |
25/40/40T |
| Tyre model |
16.00R25 E3 |
| Optional equipments |
automatic transmission, hydraulic retarder, self - cleaning air filter, oil filter |
