| Model |
CTE150A Pure Electric (Advanced) |
CTH150A Hybrid (Advanced) |
| Gross Vehicle Weight (t) |
150 |
150 |
| Overall Dimensions (L×W×H) (mm) |
10890×4225×4835 |
10890×4225×4835 |
| Cargo Box Volume (Flat Load) (m³) |
55 |
55 |
| Cargo Box Lifting Method |
Dual-cylinder Mid-mounted |
Dual-cylinder Mid-mounted |
| Wheelbase (mm) |
1820 + 2800 + 1800 |
1820 + 2800 + 1800 |
| Maximum Speed (km/h) |
40 |
40 |
| Drive Type |
8×4 |
8×4 |
| Maximum Gradeability (%) |
32 |
32 |
| Minimum Turning Diameter (m) |
25 |
25 |
| Minimum Ground Clearance (mm) |
370 |
370 |
| Motor/Engine |
EM660 Motor / TZ480XS052 |
Mining Version 770 HP Engine |
| Motor Power (kW) |
660/920kW 700/1000kW |
150/250kW |
| Battery Capacity |
845.75kWh
845.75kWh |
83.92kWh (Optional 138.5kWh) |
| Transmission |
3E560 Mining-Specific Transmission |
8-Speed Hybrid AMT Transmission |
| Axle Load (t) |
25/25/50/50T |
25/25/50/50T |
| Front Suspension |
Chitian Patented - Dual Front Axle Through-Type Oil-Gas Balanced Suspension |
Chitian Patented - Dual Front Axle Through-Type Oil-Gas Balanced Suspension |
| Rear Suspension |
Chitian Patented - Through-Type Oil-Gas Balanced Suspension |
Chitian Patented - Through-Type Oil-Gas Balanced Suspension |
| Chassis Frame |
Rigid Frame |
Rigid Frame |
| Tires |
460/95R25 Reinforced Tires |
460/95R25 Reinforced Tires |
| Safety Assistance System |
Emergency Steering + Automatic Reverse Parking System |
Emergency Steering + Automatic Reverse Parking System |
