| Model |
CT150KD |
| Empty weight |
49 |
| Overall dimensions (mm) |
10100×4000×4400 |
| Mode of drive |
8×4 |
| Wheelbase (mm) |
1820 + 2700 + 1800 |
| Maximum climb angle (%) |
32 |
| Minimum turning diameter (m) |
25 |
| Minimum ground clearance (mm) |
400 |
| Cab type |
narrow cab with left-hand position and forward tilt |
| Auxiliary safety equipment |
Reversing image system, reversing camera |
| Box volume (m³) |
53 |
| Box dimensions (mm) |
6600×3600×2100 |
| Box material and thickness (mm) |
NM450 12/16 |
| Hydraulic lifting system |
214 |
| Underbox heating system |
standard |
| Engine model |
770 |
| Steering system |
fully hydraulic |
| Gearbox |
8DS280 |
| Air filter |
electric multi-stage sand filter |
| Fuel tank (L) |
800L with fuel heating |
| Frame |
high-strength flexible frame 12 + 12 + 12 |
| Front suspension |
longitudinal spring/air suspension |
| Rear suspension |
patented 180T leaf spring suspension |
| Leaf thickness/width/number |
33/120/15 |
| Front and rear axle load capacity |
25/40/40T |
| Tyre model |
16.00R25 E3 |
| Optional equipments |
automatic transmission, hydraulic retarder, self-cleaning air filter, oil filter |
