| Model |
CTE150A Pure Electric (Advanced) |
CTH150A Hybrid (Advanced) |
| Gross Vehicle Weight (t) |
190 |
190 |
| Overall Dimensions (L×W×H) (mm) |
11330×4500×4980 |
11330×4500×4980 |
| Cargo Box Volume (Flat Load) (m³) |
62 |
62 |
| Cargo Box Lifting Method |
Dual-cylinder Mid-mounted |
Dual-cylinder Mid-mounted |
| Wheelbase (mm) |
2200 + 2600 + 1900 |
2200 + 2600 + 1900 |
| Maximum Speed (km/h) |
40 |
40 |
| Drive Type |
8×6 |
8×6 |
| Maximum Gradeability (%) |
38 |
38 |
| Minimum Turning Diameter (m) |
25 |
25 |
| Minimum Ground Clearance (mm) |
500 |
500 |
| Engine |
70 HP Engine |
70 HP Engine |
| Generator |
400kW |
400kW |
| Motor Power (kW) |
700/1000kW 210/260kW |
260/410kW |
| Battery Capacity |
424kWh
424kWh |
124.3kWh (Optional 138.5kWh, 191.2kWh) |
| Transmission |
3E560 Mining-Specific Transmission |
8-Speed Hybrid AMT Transmission |
| Axle Load (t) |
30/30/65/65T |
30/30/65/65T |
| Front Suspension |
Chitian Patented - Dual Front Axle Through-Type Oil-Gas Balanced Suspension |
Chitian Patented - Dual Front Axle Through-Type Oil-Gas Balanced Suspension |
| Rear Suspension |
Through-Type Oil-Gas Balanced Suspension |
Through-Type Oil-Gas Balanced Suspension |
| Chassis Frame |
Rigid Frame |
Rigid Frame |
| Tires |
505/95R29 Reinforced Tires |
505/95R29 Reinforced Tires |
| Safety Assistance System |
Emergency Steering + Automatic Reverse Parking System |
Emergency Steering + Automatic Reverse Parking System |
