Technical parameters
| Howard TX7/WP12.460E62+5.92 |
| Vehicle model |
ZZ3317V326GF1 |
| Motor model |
WP12.460E62 |
| Motor Net power (kw) / speed (r/min) |
338/1900 |
| Motor Maximum torque (Nm) / speed (r/min) |
2200/1000-1400 |
| Gearbox |
HW23713C+HW50 direct connection power take-off |
| Clutch (mm) |
- |
| Rear axle model |
MCP16ZG Self-adjusting arm double rear axle (drum) |
| Rear axle speed ratio |
5.92 |
| Fuel tank (L) |
400 |
| Frame section (mm) |
8+8/300 |
| Suspension (front spring rear spring) |
Front and rear reinforced multi-leaf springs (11/11/12) |
| tyre |
12.00R20 (Mixed Pattern) |
Vehicle configuration
| Vehicle parameters |
| Engine model |
WP12.460E62 |
| Shape (mm) |
9580,9780,9930,9630×2550,2520×3450,3800,3550,3200 |
| Wheelbase (mm) |
3225 |
| Front overhang Rear overhang (mm) |
1800/1350 |
| Maximum total mass (Kg) |
31000 |
| Rated number of passengers (persons) |
2 |
|
|
