Technical parameters
| Howard TX7/WP8.350E62+4.8 |
| Vehicle model |
ZZ3317V286GF1B |
| Motor model |
WP8.350E62 |
| Motor Net power (kw) / speed (r/min) |
257/2100 |
| Motor Maximum torque (Nm) / speed (r/min) |
1400/1200-1600 |
| Gearbox |
HW19712L gearbox + HW50 direct coupled power take-off |
| Clutch (mm) |
- |
| Rear axle model |
MCX16ZG Self-adjusting arm double rear axle (drum) |
| Rear axle speed ratio |
4.8 |
| Fuel tank (L) |
400 |
| Frame section (mm) |
8+4/280 |
| Suspension (front spring rear spring) |
Front and rear standard multi-leaf springs (7/7/10) |
| tyre |
11.00R20 (Mixed Pattern) |
Vehicle configuration
| Vehicle parameters |
| Engine model |
WP8.350E62 |
| Shape (mm) |
8700,8800,9000,9200,8900×2550,2520×3450,3800,3300,3550,3600,3200 |
| Wheelbase (mm) |
2825 |
| Front overhang Rear overhang (mm) |
2825 |
| Maximum total mass (Kg) |
31000 |
| Rated number of passengers (persons) |
2 |
|
|
