| Model |
LUNAII-10T |
| Nav Method |
3D Laser SLAM + Vision + GPS + IMU |
| Drive Form |
4×4 |
| Self-Wt/Load/Total Wt (t) |
6/10/16 |
| Vehicle Dim (LWH) |
4700×2435×900mm |
| Tires |
711×254 Solid Rubber Tires |
| Axles |
8t Drive-Steer Axle (Ratio 6.733) + 8t Drive-Steer Axle (Ratio 6.733) |
| Motor/Power |
PMSM/50Kw (Peak 100Kw) |
| Battery/Capacity |
HV Lithium Iron Phosphate Batt 540V/46.3Kw.h |
| Braking Sys |
Hydraulic + Mechanical Braking/Braking Dist 2m |
| Steering Sys |
Elec-Cont Full-Hydraulic Steering/Min Turning Radius 5m |
| Max Climbing Gradient (%) |
7°/12% |
| Max Speed (km/h) |
10 |
| Docking Accuracy |
±5cm |
| Laser Obstacle Stop |
Std |
| Audible-Visual Alarm |
Std |
| Mechanical Collision E-Stop |
Std |
| Emergency Stop |
Std |
| Indoor/Outdoor |
Indoor/Outdoor, Light Rain/Snow |
| Single Map Size |
≥100W㎡ |
| Working Temp |
-10~40°C |
| Network Comm |
WiFi/5G/4G |
