MeccAlte ECO46 2L4 A

380V / 400V / 415V / 380V-400V-415V
4 Pole | 50Hz | 3Phase | 0.8PF | AVR Controlled
Winding : Standard - 12 Lead / Winding : Standard - Broad Voltage - 12Lead

Model	Weight(kg)	Leads	AVR	Standby 163/27	Standby 150/40	Continuous 125/40[H]	Continuous 105/40[F]	Continuous 80/40[B]
ECO46 2L4 A	4375	12	DER-1/A	2700	2588	2500	2250	2000

440V
4 Pole | 50Hz | 3Phase | 0.8PF | AVR Controlled
Winding : Standard - 12 Lead

Model	Weight(kg)	Leads	AVR	Standby 163/27	Standby 150/40	Continuous 125/40[H]	Continuous 105/40[F]	Continuous 80/40[B]
ECO46 2L4 A	4375	12	DER-1/A	2450	2350	2280	2050	1824

480V / 460V
4 Pole | 60Hz | 3Phase | 0.8 PF | AVR Controlled
Winding: Standard - 12 Lead

Model	Weight(kg)	Leads	AVR	Standby 163/27	Standby 150/40	Continuous 125/40[H]	Continuous 105/40[F]	Continuous 80/40[B]
ECO46 2L4 A	4375	12	DER-1/A	3240	3105	3000	2700	2400

440V
4 Pole | 60Hz | 3Phase | 0.8 PF | AVR Controlled
Winding: Standard - 12 Lead

Model	Weight(kg)	Leads	AVR	Standby 163/27	Standby 150/40	Continuous 125/40[H]	Continuous 105/40[F]	Continuous 80/40[B]
ECO46 2L4 A	4375	12	DER-1/A	3067	2939	2840	2550	2272

415V / 415V-440V-460V-480V
4 Pole | 60Hz | 3Phase | 0.8 PF | AVR Controlled
Winding: Standard - 12 Lead / Winding: Standard - Bord Voltage - 12 Lead

Model	Weight(kg)	Leads	AVR	Standby 163/27	Standby 150/40	Continuous 125/40[H]	Continuous 105/40[F]	Continuous 80/40[B]
ECO46 2L4 A	4375	12	DER-1/A	2920	2800	2700	2430	2160

400V
4 Pole | 60Hz | 3Phase | 0.8 PF | AVR Controlled
Winding: Standard - 12 Lead

Model	Weight(kg)	Leads	AVR	Standby 163/27	Standby 150/40	Continuous 125/40[H]	Continuous 105/40[F]	Continuous 80/40[B]
ECO46 2L4 A	4375	12	DER-1/A	2810	2690	2600	2380	2080

380V
4 Pole | 60Hz | 3Phase | 0.8 PF | AVR Controlled
Winding: Standard - 12 Lead

Model	Weight(kg)	Leads	AVR	Standby 163/27	Standby 150/40	Continuous 125/40[H]	Continuous 105/40[F]	Continuous 80/40[B]
ECO46 2L4 A	4375	12	DER-1/A	2780	2660	2570	2355	2060

380V
4 Pole | 60Hz | 3Phase | 0.8 PF | AVR Controlled
Winding: Standard - Dedicated - 12 Lead

Model	Weight(kg)	Leads	AVR	Standby 163/27	Standby 150/40	Continuous 125/40[H]	Continuous 105/40[F]	Continuous 80/40[B]
ECO46 2L4 A	4375	12	DER-1/A	2915	2795	2700	2430	2160

600V / 690V
4 Pole | 60Hz | 3Phase | 0.8 PF | AVR Controlled
Winding: Standard - Dedicated - 12 Lead

Model	Weight(kg)	Leads	AVR	Standby 163/27	Standby 150/40	Continuous 125/40[H]	Continuous 105/40[F]	Continuous 80/40[B]
ECO46 2L4 A	4375	12	DER-1/A	3240	3105	3000	2700	2400
