| Transport type |
Complex transport |
| Logistics type |
Concrete |
| Distance (km) |
≤50 |
| Road type |
Paved roads |
| Drive |
6×4 |
6×4 |
8×4 |
| Max weight(t) |
≤35 |
≤35 |
≤50 |
| Max speed(km/h) |
≤85 |
≤70 |
≤85 |
| Loaded speed(km/h) |
45 - 60 |
40 - 60 |
45 - 60 |
| Vehicle model |
SX5255GJBR384 |
SX5255GJBR384C |
SX5315GJBHU306 |
| Engine |
WP10.336 - PTO |
ISME345 30+PTO |
WP12.420E201 - PTO |
| Emission standard |
Euro Ⅱ |
EuroⅢ |
Euro Ⅱ |
| Displacement |
9.7L |
10.8L |
11.596L |
| Rated Output |
259kW |
254kW |
280kW |
| Max. torque |
1350N·m |
1800N·m |
1500N·m |
| Transmission |
RTD11509C |
10JSD180 |
10JSD180 |
| Clutch |
430 |
430 |
430 |
| Frame |
850×300 (8+7) |
850×300 (8+7) |
850×300 (8+7) |
| Front axle |
MAN 9.5T |
MAN 9.5T |
MAN 9.5T |
| Rear axle |
16T MAN double reduction 5.92 |
16T MAN double reduction 5.262 |
16T MAN double reduction 5.262 |
| Tire |
12.00R20 |
12.00R20 |
12.00R20 |
| Front Suspension |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
| Rear Suspension |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
| Fuel |
Diesel |
Diesel |
Diesel |
| Capacity of the fuel tank |
400L (Aluminum shell) |
400L (Aluminum shell) |
400L (Aluminum shell) |
| Battery |
165Ah |
165Ah |
165Ah |
| Dimensions(L×W×H) |
8575×2495×3774 |
8575×2495×3774 |
10725×2495×3774 |
| Volume (m³) |
9 |
9 |
12 |
| Wheelbase |
3775+1400 |
3775+1400 |
1800+2975+1400 |
| Approach / Departure angle (°) |
20/18 |
20/18 |
20/18 |
| Max.gradeability(%) |
34 |
34 |
34 |
| Cab Type |
MAN H3000, lengthened flat roof |
| Cab Equipments |
Rear window
Manual sunroof
Hydraulic driver seat with seatbelts
Hydraulic suspension of cab
Automated air conditioning
Electric window
Radio with MP3 player |
| Cab Optional |
Air cushioned drivers seat
Full vehicle WABCO valve
Central locking |
