| Transport type |
Mining engineering |
| Logistics type |
One / sand / gravel / coal |
| Distance (km) |
≤200 |
| Road type |
Paved roads |
| Drive |
6×4 |
6×4 |
6×4 |
| Max weight(t) |
≤50 |
≤50 |
≤50 |
| Max speed(km/h) |
75 |
75 |
80 |
| Loaded speed(km/h) |
40 - 60 |
40 - 60 |
40 - 60 |
| Vehicle model |
SX32556T384 |
SX32556V384 |
SX32556T384C |
| Engine |
WP12.380 |
WP12.420 |
ISM 385 |
| Emission standard |
Euro Ⅱ |
Euro Ⅱ |
Euro Ⅱ |
| Displacement |
11.596L |
11.596L |
10.8L |
| Rated Output |
280kW |
309kW |
283kW |
| Max. torque |
1500N·m |
1750N·m |
1835N·m |
| Transmission |
10JS160+QH50 |
10JS180+QH50 |
12JS180T+QH50 |
| Clutch |
430 |
430 |
430 |
| Frame |
850×300 (8+7) |
850×300 (8+7) |
850×300 (8+7) |
| Front axle |
MAN 7.5T |
MAN 7.5T |
MAN 7.5T |
| Rear axle |
16T MAN double reduction 5.262 |
16T MAN double reduction 5.262 |
16T MAN double reduction 5.262 |
| Tire |
12.00R20 |
12.00R20 |
12.00R20 |
| Front Suspension |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
| Rear Suspension |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
| Fuel |
Diesel |
Diesel |
Diesel |
| Capacity of the fuel tank |
380L |
380L |
380L |
| Battery |
165Ah |
165Ah |
180Ah |
| Dimensions(L×W×H) |
7950×2490×3270 |
7950×2490×3270 |
7950×2490×3270 |
| Trunk(L×W×H) |
5600×2300×1300 |
5600×2300×1300 |
5600×2300×1300 |
| Wheelbase |
3775+1400 |
3775+1400 |
3775+1400 |
| Approach / Departure angle (°) |
28/23 |
28/23 |
28/23 |
| Max.gradeability(%) |
30 |
30 |
30 |
| Cab Type |
X3000, mid - lengthened flat roof |
| Cab Equipments |
Rear window
Automated air conditioning
Hydraulic suspension of cab
Hydraulic driver seat with seatbelts
One sleeping bed
Hydraulic reversal
Radio with MP3 player |
| Cab Optional |
Air cushioned drivers seat
Central locking |
