| Transport type |
Tanker |
| Logistics type |
Oil |
| Distance (km) |
≤300 |
| Road type |
Paved roads |
| Drive |
6×4 |
| Max weight(t) |
≤40 |
| Max speed(km/h) |
90 |
| Loaded speed(km/h) |
50- 70 |
| Vehicle model |
SX5255GYSR434 |
| Engine |
WP10.340 |
| Emission standard |
Euro Ⅲ |
| Displacement |
9.726L |
| Rated Output |
250kW |
| Max. torque |
1350N·m |
| Transmission |
10JSD140+QH50 |
| Clutch |
430 |
| Frame |
850×300 (8+5) |
| Front axle |
MAN 7.5T |
| Rear axle |
13T MAN double reduction 4.769 |
| Tire |
12.00R20 |
| Front Suspension |
Multi leaf springs |
| Rear Suspension |
Multi leaf springs |
| Fuel |
Diesel |
| Capacity of the fuel tank |
400L (Aluminum shell) |
| Battery |
165Ah |
| Dimensions(L×W×H) |
9275×2495×3774 |
| Volume (m³) |
25 |
| Wheelbase |
4375+1400 |
| Approach / Departure angle (°) |
20/18 |
| Max.gradeability(%) |
34 |
| Cab Type |
X3000, lengthened flat roof |
| Cab Equipments |
Rear window
Manual sunroof
Hydraulic driver seat with seatbelts
Hydraulic suspension of cab
Electronic air conditioning with temperature control
Electric window
Radio with MP3 player |
| Cab Optional |
Air cushioned drivers seat
Central locking |
|
|
