| Model |
4CBM-SWEEPER |
| Chassis Brand |
ISUZU |
| Overall Dimension |
5850*2000*2530mm
|
| GVW/Kerb Weight |
7000kg/4150kg |
| Cab Capacity |
3 persons allowed |
| Air Conditioner |
Heating/cooling air conditioner |
| Fuel Type |
Diesel |
| Engine Brand |
ISUZU |
| Power |
98 HP |
| Displacement |
2777ml |
| Emission Standard |
Euro IV or V |
| Drive Type |
4X2(left hand drive) |
| Transmission |
ISUZU MSB 5 speed levers with 1 reverse |
| Wheelbase/No. of axle |
3360 mm/2 |
| Tire Specification |
7.00-15 |
| Tire Number |
6 tires and 1 spare tire |
| Max Speed |
95 km/h |
| Paint |
Metallic paint |
| Body capacity |
4cbm |
| Water tank |
1000 liters |
| Sweeping width |
3-20km/h |
| Filling work cycly time |
20~25 s |
| Max sweeping |
65000m2/h |
| Control system |
Electrically Hydraulic control |
| Control panel |
English or Your language |
|
|
