| Model |
ZL20EFB(D) |
| Dimensions (L×W×H)(mm) |
(6315±180)×(1960±50)×(2190±50) |
| Engine Model |
KC4107DZLQFB(A) |
| Rating power(KW) |
80 |
| Maximum output torque(N·m) |
380 |
| Torque converter |
Hydro-mechanical |
| Gearbox |
3 forward gears, 3 reverse gears |
| Service brakes |
Four-wheel braking, Hydraulic brake, Wet brake |
| Parking brake |
Fail-safe wet brake |
| Emergency braking |
Fail-safe wet brake |
| Drive form |
4X4 |
| Unloading method |
Side discharge |
| Rated load weight(Kg) |
2000 |
| Wheelbase(mm) |
2260 ± 65 |
| Wheelbase specifications |
16/70-20 |
| Maximum unloading height(mm) |
3050(side discharge) |
| Maximum gradeability(%) |
≥25(14°) |
|
|
