| Transport type |
Highway transport |
Full drive dump truck |
| Logistics type |
Ore / sand / gravel / coal |
Ore / sand / gravel / coal |
| Distance (km) |
≤200 |
≤200 |
| Road type |
Offroad |
Offroad |
| Drive |
8×4 |
8×4 |
8×4 |
4×4 |
6×6 |
| Max weight(t) |
≤90 |
≤90 |
≤90 |
≤25 |
≤50 |
| Max speed(km/h) |
75 |
75 |
75 |
75 |
75 |
| Loaded speed(km/h) |
40~60 |
40~60 |
40~60 |
40~60 |
40~60 |
| Vehicle model |
SX3315DT326 |
SX3315DV366 |
SX3315DT366C |
SX3165DR442 |
SX3255DV385 |
| Engine |
WP12.380 |
WP12.420 |
ISM 385 |
WP10.340 |
WP12.420 |
| Emission standard |
Euro Ⅱ |
Euro Ⅱ |
Euro Ⅲ |
EuroⅡ |
Euro Ⅱ |
| Displacement |
11.596L |
11.596L |
10.8L |
9.726L |
11.596L |
| Rated Output |
280kW |
309kW |
283kW |
250kW |
309kW |
| Max. torque |
1500N·m |
1750N·m |
1835N·m |
1350N·m |
1750N·m |
| Transmission |
10JSD160+QH50 |
10JSD180+QH50 |
12JSD180T+QH50 |
10JSD200T140+QH50 |
10JSD180+QH50 |
| Clutch |
430 |
430 |
430 |
430 |
430 |
| Frame |
850×300(8 + 7) |
850×300(8 + 7) |
850×300(8 + 7) |
850×300(8 + 7) |
850×300(8 + 7) |
| Front axle |
MAN 7.5T |
MAN 7.5T |
MAN 7.5T |
STR 6.5T |
STR 6.5T |
| Rear axle |
16T STR double reduction 5.73 |
16T STR double reduction 5.73 |
16T STR double reduction 5.73 |
16T STR double reduction 5.73 |
16T MAN double reduction 5.92 |
| Tire |
11.00R20 |
12.00R20 |
12.00R20 |
12.00R20 |
12.00R20 |
| Front Suspension |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
| Rear Suspension |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
Multi leaf springs |
| Fuel |
Diesel |
Diesel |
Diesel |
Diesel |
Diesel |
| Capacity of the fuel tank |
380L |
380L |
380L |
380L |
380L |
| Battery |
165Ah |
165Ah |
180Ah |
135Ah |
135Ah |
| Dimensions(L×W×H) |
8950×2490×3270 |
9300×2490×3210 |
9300×2490×3210 |
6750×2490×3270 |
7950×2490×3270 |
| Trunk(L×W×H) |
6800×2300×1300 |
7400×2300×1500 |
7400×2300×1500 |
4500×2300×1100 |
5600×2300×1300 |
| Wheelbase |
1800+3175 + 1400 |
1800+3575 + 1400 |
1800+3575 + 1400 |
4400 |
3775 + 1400 |
| Approach / Departure angle (°) |
28/55 |
28/55 |
28/55 |
28/55 |
28/55 |
| Max.gradeability(%) |
30 |
30 |
25 |
25 |
25 |
| Cab Type |
MAN F2000, mid-lengthened flat roof |
| Cab Equipments |
Rear window
Mechanical clerestory
Hydraulic suspension of cab
Hydraulic driver seat with seatbelts
One sleeping bed
Hydraulic reversal
Radio with MP3 player |
| Cab Optional |
Air cushioned drivers seat
Front lamp protection grid |
