| Model |
QM2 |
| Overall Dimensions (Length×Width×Height) |
5500×1500×1850 |
| Weight of Complete Machine(kg) |
5600 |
| Control Mode |
Electro - hydraulic Proportional Control |
| Impact Energy(J) |
125 |
| Impact Frequency(bpm) |
700 - 1200 |
| Drill Rod Diameter(mm) |
Φ45 |
| Maximum Extension Length(mm) |
4800 |
| Maximum Picking Height(mm) |
6000 |
| Steering System |
Articulated |
| Turning Radius/Inner Diameter(mm) |
≤2100 |
| Turning Radius/Outer Diameter(mm) |
≤3700 |
| Gradeability(°) |
≤14 |
| Drive Form |
Diesel Engine |
| Minimum Ground Clearance(mm) |
≥200 |
| Frame Swing Angle(°) |
±7 |
| Vehicle Body Steering Angle(°) |
±40 |
| Fuel Tank Capacity(L) |
90 |
| Travel Speed/Forward(km/h) |
Gear Ⅰ: 2.9, Gear Ⅱ: 7.1, Gear Ⅲ: 8.0 |
| Travel Speed/Backward(km/h) |
Gear Ⅰ: 2.9, Gear Ⅱ: 7.1 |
| Diesel Engine Brand |
Yanmar |
| Rated Power of Diesel Engine(kw) |
36 |
| Exhaust Emission of Diesel Engine |
Comply with National IV Emission Standard |
