| Model |
EC260 |
| Operating weight |
62,744 - 75,663 lbs |
| Gross power |
225 hp |
| ...at engine speed |
1,350 rpm |
| Bucket capacity |
0.6 - 2.3 yd³ |
| Lifting capacity, along undercarriage |
19,840 lbs |
| ...at reach / height |
15 ft |
| Max. digging reach |
32' 8" ft in |
| Max. digging depth |
21' 7" ft in |
| Breakout force, SAE J1179 (Normal) |
32,600 lbf |
| Breakout force, SAE J1179 (Boost) |
35,290 lbf |
| Tear out force, SAE J1179 (Normal) |
29,670 lbf |
| Tear out force, SAE J1179 (Boost) |
32,150 lbf |
| Overall width |
10'6" ft in |
| Tail swing radius |
10'1" ft in |
|
All specifications are approximate. Specifications are subject to change without notice.
|
|
|
