| Model |
12M26.3 |
| Type |
Four-stroke,water cooled,in-line/V type turbocharged and aftercooled |
| Bore&Stroke |
150*150(mm) |
| Oil consumption rate |
<=0.5g/kW/h |
| Minimum fuel consumption rate |
200g/kW/h |
| Rotation(facing the flywheel) |
Counter-colockwise |
| Torque reserve |
20-30% |
| Dimensions(L*W*H) |
L6:2103*1172*1196mm/ V12:2333*1350*1494mm |
| Number of cylinders |
6/12 |
| Displacement |
15.9/31.8L |
| Noise |
<=100dB(A) |
| Idle speed |
650±50r/min |
| Net weight |
1985/3300kg |
| Aspiration |
TA |
| Rated power(kW/Ps) |
883/1200 |
970/1320 |
1303/1400 |
1104/1500 |
1214/1650 |
| Speed r/min |
1800 |
1800 |
2100 |
2200 |
2300 |
| Fuel system |
HPCR |
| Emission |
IMO II/IMO III/EPA IV |
IMO II |
IMO II/IMO III/EPA III |
IMO II/IMO III/EPA IV |
IMO II/IMO III/EPA IV |
| Power rating |
P1 |
P2 |
P2 |
P2 |
P3 |
|
|
