WEICHAI 12WH17C1564-2

12WH17C1564-2 - LGMG 12WH17C1564-2 WEICHAI Marine Engine

Model	12WH17C1564-2
Type	Four-stroke,water cooled,in-line,turbocharged and aftercooled
Bore&Stroke	170*220(mm)
Oil consumption rate	<=0.3g/kW/h
Minimum fuel consumption rate	200g/kW/h
Rotation(facing the flywheel)	Counter-colockwise
Dimensions(LWH)	225613311856mm
Number of cylinders	12
Displacement	54.48L
Noise	<=111dB(A)
Idle speed	650±30r/min
Net weight	5300kg
Aspiration	TA
Rated power(kW/Ps)	1150/1564
Speed r/min	1200
Fuel system	HPCR
Emission	IMO II
Power rating	P1

All specifications are approximate. Specifications are subject to change without notice.
