LONKING CDM520A9

H.S.8429 5100 00



CDM520A9 - LONKING CDM520A9 - Road Roller CDM520A9

Model CDM520A9
Operating Weight 20000kg
Drum Width 2120 mm
Drum Diameter 1600 mm
Centrifugal Force 356/248 kN
Vibration Frequency 28/33 Hz
Nominal Amplitude 1.9/0.9 mm
Static Linear Load 469 N/cm
Overall Dimension(L×W×H) 6260×2388×3183mm
Engine Model WP6G175E301 WEICHAI
Rated Power 129 kW @ 2000 rpm
Travel Speed 2.28/4.45/7.24 km/h (Forward), 2.5/5.0 km/h (Reverse)
Fuel Tank Capacity 335 L
LONKING Road Roller

LONKING CDM510B
LONKING CDM512B
LONKING CDM514B（Nation II)
LONKING CDM514B（Nation III）
LONKING CDM516B
LONKING CDM520B9
LONKING CDM512D
LONKING CDM514D
LONKING CDM520D
LONKING CDM520A9
LONKING CDM5033DG

All specifications are approximate. Specifications are subject to change without notice.
