LONKING CDM520B9

H.S.8429 5100 00



CDM520B9 - LONKING CDM520B9 - Road Roller CDM520B9

Model CDM520B9
Operating Weight 20000kg
Drum Width 2130 mm
Drum Diameter 1600 mm
Centrifugal Force 356/248 kN
Vibration Frequency 28 Hz
Nominal Amplitude 1.9/0.9 mm
Static Linear Load 469 N/cm
Overall Dimension(L×W×H) 6260×2388×3200mm
Engine Model WP6G175E301 Weichai
Rated Power 129 kW @ 2000 rpm
Travel Speed 2.3/4.5/9.6 km/h
Fuel Tank Capacity 335 L
