| Model |
835T(Tier3/StageIII) |
835T(Tier3/StageIII) |
835T(Tier2/StageII) |
| Operating weight |
10300 kg |
10,800 kg |
10,100 kg |
| Rated Power |
113 kW (152 hp / 154 ps) @ 2,200 rpm |
110 kW (148 hp / 150 ps) @ 2,000 rpm |
92 kW (123 hp / 125 ps) @ 2,000 rpm |
| Raise |
5.1 s |
4.7s |
5.5 s |
| Tipping Load - Full Turn |
7,121 kg |
7,100kg |
7,700 kg |
| Dump Clearance at Full Height Discharge |
2,996 mm |
2,918 mm |
3,000 mm |
| Model |
Cummins QSB5.9 |
Yuchai YCA05K150 |
Yuchai YC6J125Z |
| Aspiration |
Turbocharged & Air-to-air intercooled |
Turbocharged & Air-to-air intercooled |
Turbocharged |
| Width over Tires |
2,295 mm |
2,295 mm |
2,295 mm |
| Turning Radius, Outside of Tire |
5,113 mm |
5,113 mm |
5,090 mm |
| GP Bucket |
1.8-3.2 m3 |
1.7-3.0 m3 |
1.7-3.0 m3 |
| Standard Bucket Capacity |
1.8 m3 |
2.0 m3 |
1.8 m3 |
| Total Hydraulic Cycle Time |
9.7 s |
9.1 s |
9.7 s |
| Maximum Travel Speed, fwd |
39.4 km/h |
40 km/h |
38 km/h |
| Bucket Breakout Force |
113KN |
102kN |
107KN |
| Dump Reach at Full Height Discharge |
1,091 mm |
1,109 mm |
1,034 mm |
| Emission Rating |
Tier 3/Stage III |
Tier 3/Stage III |
Tier 2/Stage II |
| Length with Bucket Down |
6,947 mm |
7,175 mm |
7,175 mm |
| Cab Height |
3,270 mm |
3,270 mm |
3,340 mm |
| Bucket Capacities |
1.8-3.2 m3 |
1.8-3.2 m3 |
1.5-3.0 m3 |
| Light Material Bucket |
/ |
/ |
3.2 m3, 3.5 m3 |
|
|
