| Model |
FCB-5 |
| Dimensions (L×W×H)(mm) |
(5330±160)×(1950±60)×(2230±60) |
| Engine Model |
QSB4.5-C110-30 |
| Rating power(KW) |
82KW |
| Maximum output torque(N·m) |
488N·m |
| Clutch |
Diaphragm Spring Clutch |
| Gearbox |
Mechanical gearbox |
| Service brake |
Four-wheel brake, hydraulic brake, wet brake |
| Parking brake |
Fail-safe wet brake |
| Emergency braking |
Fail-safe wet brake |
| Drive form |
4x2 |
| Vehicle structure type |
Flathead Split Body |
| Rated load weight(Kg) |
5000Kg |
| Rated capacity |
/ |
| Wheelbase(mm) |
3100 |
| Wheelbase specifications(front/rear) |
1640/1515 |
| Maximum unloading height(mm) |
160 |
| Minimum Ground Clearance(mm) |
/ |
| Maximum gradeability(%) |
≥ 25(14° ) |
|
|
