| Model |
WC19RJ |
| Dimensions (L×W×H)(mm) |
5850±170×1980±60×2250±65 |
| Engine Model |
KC4107DZLQFB(B) |
| Rated power (KW) |
80kw / 2200r/min |
| Maximum output torque(N·m) |
385N·m/1500rpm |
| Clutch |
Single Dry Diaphragm Clutch |
| Gearbox |
Mechanical gearbox |
| Service brake |
Four-wheel braking,Hydraulic brake,Wet brake |
| Parking brake |
Fail-safe wet brake |
| Emergency braking |
Fail-safe wet brake |
| Drive form |
4X4 time-shift four-wheel drive |
| Vehicle structure type |
Flathead Split Body |
| Rated capacity |
19 people |
| Wheelbase(mm) |
3100 |
| Wheelbase front/rear (mm) |
1660/1660 |
| Minimum ground clearance(mm) |
200 |
| Maximum gradeability(%) |
≥25(14°) |
|
|
